Description
APPLICATIONS
● Emergency situation
● Patient transport
MAIN FEATURES
● Practical functions and convenient operation.
● High-quality main components with high reliability.
● Complete alarm system.
● Instantaneous automatic pressure relief for overpressure protection.
ENVIRONMENTAL REQUIREMENTS
● Storage temperature: -18~50℃
● Relative humidity: ≤95% (non-condensing)
● Atmospheric pressure: 70~110kPa
● Gas source: medical oxygen at 280~ 600kPa
● Power: AC 100-240V, 50/60Hz, 30VA
● Internal power supply: Lithium-ion Battery, 12V/2200mAh
STANDARD CONFIGURATIONS
● Main unit
● Mask
● Active exhalation valve
● Respiratory tubes
● Expiratory control sampling tube
● Oxygen tubing
● Oxygen regulator
● Carrying bag
OPTIONAL
● Oxygen cylinder
MAIN PARAMETERS
● Ventilation mode: CMV
● Respiratory rate: 5 ~ 40bpm (step value 1bpm), ±10%
● I:E ratio: 1:2, ±10%
● Minute ventilation: 0 ~ >20L/min (adjustable)
● FiO2: Air mixed in (50 ~ 80%) or No Air mixed in (90 ~ 100%), ±3%
● MAWP (maximum allowable working pressure): ≤8.0kPa
● Continuous running time: 24 hours on AC power; not less than 8 hours on batteries
SAFETY MEASURES
● Low voltage: Medium priority alarm
● Depleted battery: High priority alarm
● High airway pressure:
● Medium priority alarm when the airway pressure is above 5.5kPa;
● Automatic pressure relief when the airway pressure exceeds 8kPa.
